Game Boy Link Cable DMG-07/DMG-04
Game Boy Link Cable DMG-07/DMG-04
| Pin # |
Name |
Description |
DMG-07 Color |
DMG-04 Color
|
| 1 |
VCC |
5V |
Brown |
N/A
|
| 2 |
SO |
Serial Out |
Red |
Red/Orange
|
| 3 |
SI |
Serial In |
Yellow |
Orange/Red
|
| 4 |
SD |
CPU pin 14 |
N/A |
N/A
|
| 5 |
SC |
Clock |
Green |
Green
|
| 6 |
GND |
Ground |
Blue |
Blue
|
| S |
Shield |
Ground |
Bare |
Bare
|
Cartridge
Pins numbered left to right, cartridge label up.
| Pin |
Function |
Pin |
Function |
Pin |
Function |
Pin |
Function
|
| 01 |
+5V |
11 |
Address Bit 5 |
21 |
Address Bit 15 |
31 |
AUDIO IN
|
| 02 |
CLOCK |
12 |
Address Bit 6 |
22 |
Data Bit 0 |
32 |
GROUND
|
| 03 |
WRITE
|
13 |
Address Bit 7 |
23 |
Data Bit 1
|
| 04 |
READ
|
14 |
Address Bit 8 |
24 |
Data Bit 2
|
| 05 |
CHIP SELECT
|
15 |
Address Bit 9 |
25 |
Data Bit 3
|
| 06 |
Address Bit 0 |
16 |
Address Bit 10 |
26 |
Data Bit 4
|
| 07 |
Address Bit 1 |
17 |
Address Bit 11 |
27 |
Data Bit 5
|
| 08 |
Address Bit 2 |
18 |
Address Bit 12 |
28 |
Data Bit 6
|
| 09 |
Address Bit 3 |
19 |
Address Bit 13 |
29 |
Data Bit 7
|
| 10 |
Address Bit 4 |
20 |
Address Bit 14 |
30 |
RESET
|
